07HVP-681K-51 | Fastron
Suppressor choke, radial, 680 µH, 570 mA, 07HVP-681K-51
Unit Price (€ / pc.)
1.1067 € *
Standard delivery time from the manufacturer is: 18 Weeks
Total Price:
1.11 € *
Price list
Quantity
Price per unit*
1 pcs.
1.1067 €
10 pcs.
0.9758 €
100 pcs.
0.8330 €
500 pcs.
0.7259 €
1000 pcs.
0.6545 €
*incl. VAT plus shipping costs
Subject to prior sale
Pluggable inductors, type Fastron 07HVP.
Radial connections, AEC-Q200 tested
Technical specifications
| Filter | Property | Value |
|---|---|---|
| DC current | 570 mA | |
| DC resistance | 1.57 Ω | |
| Saturation current | 680 mA | |
| Measuring frequency | 1 kHz | |
| Tolerance | ±10 % | |
| Length | 10 mm | |
| Inductance | 680 µH | |
| Design | radial | |
| Version | suppressor choke |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MY |
| Original Packaging | Reel with 1 piece |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
