V10H275AUTO | Littelfuse

Varistor, radial, VV 430 V, 3500 A, 350 V (DC), 275 V (AC), 70 J, V10H275AUTO

Order No.: 74P6102
EAN: 4099891829674
MPN:
V10H275AUTO
Series: AUMOV
V10H275AUTO Littelfuse Varistors
Image may differ
Unit Price (€ / pc.)
0.5474 € *
Standard delivery time from the manufacturer is: 22 Weeks
Total Price:
1,970.64 € *
*incl. VAT plus shipping costs
Subject to prior sale
3600 pcs.
0.5474 €

Varistor, V10H275AUTO, Littelfuse

V10H275AUTO is a Silicone Coated, Radial Leaded Varistor designed for automotive applications requiring load dump, jump start and surge voltage transient protection. The V10H275AUTO offers great surge withstanding capability for low DC voltage applications.

Features

  • Reduced footprint and volume required for voltage surge protection
  • Lead-free, halogen-free, and RoHS compliant
  • Meets the stringent quality standards of AEC-Q200

Applications

  • Body electronics systems
  • Powertrain systems
  • Infotainment system
  • Automotive control module protection
  • Motor or inductive load transient suppression
Technical specifications
Filter Property Value
Grid 8.5 mm
min. operating temperature -40 °C
max. operating temperature 125 °C
Rated voltage (AC) 275 V
Rated voltage (DC) 350 V
Varistor Voltage Type 430 V
max. Surge current, transient (8/20 µs) 3500 A
Design radial
Energy absorption 70 J
Logistics
Property Value
Customs tariff number 85334090
Country of origin CN
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
