AC03000001501JAC00 | Vishay
Wirewound resistor, 1.5 kΩ, 3 W, ±5 %, AC03000001501JAC00
Unit Price (€ / pc.)
0.7378 € *
Available: 413 pcs.
Next delivery: 500 pcs. on 2025-09-15
Total Price:
0.74 € *
Price list
Quantity
Price per unit*
1 pcs.
0.7378 €
10 pcs.
0.4641 €
50 pcs.
0.3689 €
250 pcs.
0.3213 €
1000 pcs.
0.2701 €
*incl. VAT plus shipping costs
Subject to prior sale
Wirewound resistor, AC03000001501JAC00, Vishay
The AC03000001501JAC00 is a cemented leaded wirewound resistor perfect choice for general purpose power electronics, industrial and automotive electronics applications. The robust silicone cement coating can handle challenging ambient and operating conditions. Typical applications include but are not limited to pre-charging, discharging, snubber and in-rush current limiting.
Features
- High power dissipation in small design
- Excellent pulse load capability
- Flameproof insulation coating
Applications
- Industrial electronics
- Energy meter
- Power supplies
- White goods
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 275 °C | |
| diameter | 4.8 mm | |
| Version | wirewound resistor | |
| ohmic resistance | 1.5 kΩ | |
| Assembly | THT | |
| Temperature coefficient | -80/+140 ppm/K | |
| Power | 3 W | |
| Tolerance | ±5 % | |
| min. operating temperature | -40 °C | |
| Design | axial | |
| Length | 13 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CZ |
| Customs tariff number | 85332100 |
| Original Packaging | Reel with 500 pieces |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
