77A-681M-00 | Fastron
Suppressor choke, radial, 680 µH, 1 A, 77A-681M-00
Unit Price (€ / pc.)
1.7612 € *
Available in 4 Days: 104 pcs. - if ordered today
Total Price:
1.76 € *
Price list
Quantity
Price per unit*
1 pcs.
1.7612 €
10 pcs.
1.5470 €
100 pcs.
1.3209 €
500 pcs.
1.1543 €
1000 pcs.
1.0472 €
*incl. VAT plus shipping costs
Subject to prior sale
Suppressor inductor, 77A-681M-00, FASTRON
The 77A-681M-00 is a suppression coil which protects sensitive equipment from the transient voltage (back EMF) generated from the coil during de-energization.
Applications
- Communication
- RF blocking
- Filtering and Decoupling
- Entertainment electronics
- Interference suppression
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Design | radial | |
| DC current | 1 A | |
| Inductance | 680 µH | |
| Version | suppressor choke | |
| Length | 26 mm | |
| Tolerance | ±20 % | |
| DC resistance | 1.2 Ω |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| Country of origin | MY |
| Original Packaging | Reel with 300 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
