THD 12-4811WI | TRACO POWER

DC converter, 18-75 VDC, 12 W, 1 output, 5.1 VDC, 85 % efficiency, THD 12-4811WI

Order No.: 26K3258
EAN: 4099891300982
MPN:
THD 12-4811WI
Series: THD 12WI
THD 12-4811WI TRACO POWER DC/DC Converters Image 1
THD 12-4811WI TRACO POWER DC/DC Converters Image 2
Image may differ
Unit Price (€ / pc.)
44.1371 € *
Standard delivery time from the manufacturer is: 20 Weeks
Total Price:
44.14 € *
Price list
Quantity
Price per unit*
1 pcs.
44.1371 €
10 pcs.
39.7103 €
*incl. VAT plus shipping costs
Subject to prior sale

DC converters, type Traco THD 12WI.

12 W converter with 4 : 1 extended-range inputs in DIL-24 metal package, sustained short circuit-proof, low-voltage cut-off, external On/Off, industrial standard pinning. Input voltage fluctuation: ±0.2 %. Load fluctuation on single/dual output: ±0.5/±1.0 %. Residual ripple: 85 mVpp. I/O insulation voltage: 1500 VDC. Efficiency: 85 %. Operating temperatures: –40 to +85 °C.

Technical attributes (type, input voltage range, output voltage/output current): THD 12-4811WI, 18 - 75 VDC, 1 x OUT, 5.1 VDC/2.4 A

Technical specifications
Filter Property Value
Number of outputs 1
Output current 2.4 A
Output voltage DC 5.1 VDC
Input voltage AC 18-75 VDC
Power 12 W
efficiency 85 %
Design DIP24
Isolation voltage 1.5 kV
Length 31.8 mm
Width 20.3 mm
Height 10.2 mm
Logistics
Property Value
Country of origin TW
Customs tariff number 85044095
Compliance
Property Value
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
