015401.5DR | Littelfuse
SMD fuse 9.73 x 5.03 mm, 1.5 A, FF, 125 V (DC), 125 V (AC), 50 A breaking capacity, 015401.5DR
Unit Price (€ / pc.)
1.9873 € *
Standard delivery time from the manufacturer is: 8 Weeks
SMD-Fuse, 015401.5DR,LITTELFUSE
The 015401.5DR is a very fast-acting fuse that allows for a temporary current surge without going above the fuse's current rating. Because of this time delay fuses are most commonly used to protect motor circuits.
Features
- Easy fuse replacement
- Miniature size
- Wide operating temperature range
- High breaking capacity
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 125 V | |
| Rated voltage (AC) | 125 V | |
| Length | 9.73 mm | |
| Height | 3.81 mm | |
| Tripping characteristics | FF | |
| Width | 5.03 mm | |
| Breaking capacity | 50 A | |
| Design | 9.73 x 5.03 mm | |
| Enclosure | SMD | |
| Version | SMD fuse | |
| Rated current | 1.5 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PH |
| Original Packaging | Reel with 1,500 pieces |
| Customs tariff number | 85361010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
