52100314 | LAPP
Extension piece, M50 to M63, 70 mm, light gray, 52100314
Order No.: 33P6713
EAN: 4056158596366
MPN:
52100314
SKINDICHT EKU-M 50X1,5/63X1,5 BK
Series: SKINDICHT EKU-M
Unit Price (€ / pc.)
16.4696 € *
Standard delivery time from the manufacturer is: 6 Weeks
Extension piece, 52100314, LAPP
The 52100314 metric cable gland accessories for cable glands with larger connection threads than the existing threaded holes.
Features
- Assembling with a wrench
- Supporting surface for spanner means scratches on the housing are avoided
Applications
- Machines
- Devices
- Housings
Technical specifications
| Filter | Property | Value |
|---|---|---|
| spanner size | 70 mm | |
| max. operating temperature | 100 °C | |
| Thread size | M50 to M63 | |
| Colour | light gray | |
| Material | PA | |
| min. operating temperature | -40 °C | |
| Product type | extension piece |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | QU |
| Customs tariff number | 39269097 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
