1224430000 | Weidmüller
Weidmueller SAI-M23-SE-19-F-PE
Unit Price (€ / pc.)
25.9301 € *
Available: 0 pcs.
Leadtime: 3 Weeks **
Total Price:
25.93 € *
Price list
Quantity
Price per unit*
1 pcs.
25.9301 €
10 pcs.
24.1094 €
50 pcs.
22.1816 €
*incl. VAT plus shipping costs
**Subject to prior sale
Sensor-actuator connector, 1224430000, WEIDMÜLLER
The 1224430000 is a round plug-in connector that offers a high number of mating cycles, high current-carrying capacity and high contact-density coupled with minimum dimensions.
Features
- Contact surface: Gold-plated
- 19 contacts
- Pollution degree: 3
- High mating cycles
Technical specifications
| Version | plug | |
| Thread size | M23 | |
| Contact connection | solder connection | |
| contact surface | gold-plated | |
| Pin number | 19 pole | |
| Degree of protection (IP) | IP67/IP69K |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
