MMU01020C4300FB300 | Vishay
Resistor, thin film, SMD 0102, MicroMELF, 430 Ω, 0.2 W, ±1 %, MMU01020C4300FB300
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
0.0595 € *
Standard delivery time from the manufacturer is: 10 Weeks
SMD thin-film resistors, size 0102, Micro-MELF, 0.2 W, tolerance 1.0 %, type Vishay/Beyschlag MMU 0102 Professional.
Stability class: 0.25. Load rating at +70 °C: 0.2 W. Rated voltage: 150 V. Maximum voltage to environment: 200 VDC/1.0 min, continuous 75 VDC. Temperature coefficient: TC ±50. Surface temperature: max. +125 °C. IEC climate category: 55/125/56. Sliding scale prices are valid exclusively for the quantity per resistance value ordered.
Type: 430R
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ohmic resistance | 430 Ω | |
| Tolerance | ±1 % | |
| Power | 0.2 W | |
| Design | SMD 0102 | |
| Enclosure | MicroMELF | |
| Temperature coefficient | ±50 ppm/K | |
| Technology | thin film | |
| min. operating temperature | -55 °C | |
| max. operating temperature | 155 °C | |
| Length | 2.2 mm | |
| diameter | 1.1 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Original Packaging | Reel with 3,000 pieces |
| Customs tariff number | 85332100 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
