70108832 | PEPPERL+FUCHS
IO link master, PROFINET, Modbus, OPC UA, MQTT, push-in (8 input / 8 output), 70108832
Order No.: 28G8115
EAN: 4050143395507
MPN:
70108832
ICE3-8IOL-K45P-RJ45
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
681.7748 € *
Standard delivery time from the manufacturer is: 1 Week
IO-Link master, ICE3-8IOL-K45P-RJ45, PEPPERL+FUCHS
PROFINET IO IO-Link master with 8 inputs/outputs, DIN rail, push-in terminals.
Features
- Web-based configuration of module and IO-Link devices
- Integrated IODD storage for more than 100 IODDs
- Downloadable module configuration
- PROFINET IO, Modbus/TCP and OPC UA Support
- Pluggable push-in connectors
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Power Input | push-in | |
| Bus Input | RJ45 | |
| Bus Output | RJ45 | |
| Protocol | PROFINET, Modbus, OPC UA, MQTT | |
| IO Ports | push-in (8 input / 8 output) | |
| Degree of protection (IP) | IP20 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | US |
| Customs tariff number | 85176200 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
