70103603 | PEPPERL+FUCHS
IO link master, Ethernet/IP, PROFINET, M12 (8 input / 8 output), 70103603
Order No.: 28G8112
EAN: 4050143427000
MPN:
70103603
ICE1-8IOL-S2-G60L-V1D
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
486.6624 € *
Standard delivery time from the manufacturer is: 8 Weeks
IO-Link master, ICE1-8IOL-S2-G60L-V1D, PEPPERL+FUCHS
Ethernet IO-Link master with PROFINET S2 redundancy.
Features
- Multiprotocol-compatible
- M12 power connector
- Sturdy metallic housing
- Web-based configuration
- PROFINET S2 system redundancy
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Power Input | M12 | |
| Bus Input | M12 (D coded) | |
| Bus Output | M12 (D coded) | |
| Protocol | Ethernet/IP, PROFINET | |
| IO Ports | M12 (8 input / 8 output) | |
| Degree of protection (IP) | IP65/IP67/IP69K |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85176200 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
