4-1419144-7 | OEG
Relay, 1 Form A (N/O), 12 V (DC), 320 Ω, 10 A, 30 V (DC), monostable, 4-1419144-7
Order No.: 30G8484
MPN:
4-1419144-7
Unit Price (€ / pc.)
1.7850 € *
Available in 5 Days: 2,925 pcs. - if ordered today
Total Price:
1.79 € *
Price list
Quantity
Price per unit*
1 pcs.
1.7850 €
10 pcs.
1.6541 €
25 pcs.
1.5470 €
50 pcs.
1.4042 €
*incl. VAT plus shipping costs
Subject to prior sale
General Purpose Power Relay, 4-1419144-7, OEG
General Purpose Power Relay, DC, Monostable, 1 Form A SPST-NO, 10 A Contact Rating, 12 VDC Coil Voltage, 250 VAC Contact Voltage.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Coil type | monostable | |
| Connection | solder pin | |
| Coil resistance | 320 Ω | |
| Coil voltage (DC) | 12 V | |
| switching current | 10 A | |
| Contact type | 1 Form A (N/O) | |
| Contact material | AgCdO | |
| Switching Voltage (DC) | 30 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85364900 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
