B500C3700-2200A | Diotec
Diotec bridge rectifier, 500 V, 1 kV (RRM), 3.7 A, SIL, B500C3700-2200A
Unit Price (€ / pc.)
2.7013 € *
Available: 126 pcs.
Leadtime: 3 Weeks **
Total Price:
2.70 € *
Price list
Quantity
Price per unit*
1 pcs.
2.7013 €
10 pcs.
2.2729 €
100 pcs.
1.9397 €
250 pcs.
1.7493 €
1000 pcs.
1.6184 €
*incl. VAT plus shipping costs
**Subject to prior sale
Diode bridge rectifier, B500C3700-2200A, DIOTEC
Features
- Four diodes in bridge configuration
- For free-standing or heatsink assembly
- UL recognized
- Compliant to RoHS, REACH and conflict minerals
Applications
- 50/60 Hz mains rectification
- Power supplies
- Commercial grade
Technical specifications
| Version | 1-phase | |
| Assembly | THT | |
| Enclosure | SIL | |
| Input voltage | 500 V | |
| Rated current | 3.7 A | |
| Voltage V RRM (peak reverse voltage) | 1 kV | |
| min. operating temperature | -50 °C | |
| max. operating temperature | 150 °C |
Download
Logistics
| Country of origin | SI |
| Customs tariff number | 85411000 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
