B250C3700A | Diotec

Diotec bridge rectifier, 250 V, 600 V (RRM), 2.2 A, SIL, B250C3700A

Order No.: 09S3844
EAN: 4099879036360
MPN:
B250C3700A
Series: BxC3700
Diotec
B250C3700A Diotec Bridge Rectifiers
Image may differ
Print
Key Specification:
Version 1-phase
Assembly THT
Enclosure SIL
Input voltage 250 V
Rated current 2.2 A
Show 6 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
1.3685 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Add to Cart
Total Price:
1.37 € *
*incl. VAT plus shipping costs
**Subject to prior sale
500 pcs.
1.3685 €
Description
Technical specifications
Download
Logistics
Compliance
Variations

Diode bridge rectifier, B250C3700A, DIOTEC

Features

  • Four diodes in bridge configuration
  • For free-standing or heatsink assembly
  • UL recognized
  • Compliant to RoHS, REACH and conflict minerals

Applications

  • 50/60 Hz mains rectification
  • Power supplies
  • Commercial grade
Technical specifications
Version 1-phase
Input voltage 250 V
Enclosure SIL
max. operating temperature 150 °C
min. operating temperature -50 °C
Assembly THT
Rated current 2.2 A
Voltage V RRM (peak reverse voltage) 600 V
Show similar products 0
Logistics
Country of origin IN
Customs tariff number 85411000
Original Packaging Bulk with 500 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
