HD6050 | CRYDOM
Solid state relay, 3-32 VDC, zero voltage switching, 50 A, PCB mounting, HD6050
Unit Price (€ / pc.)
113.8354 € *
Available: 0 pcs.
Leadtime: 25 Weeks **
Total Price:
113.84 € *
Price list
Quantity
Price per unit*
1 pcs.
113.8354 €
5 pcs.
108.1353 €
10 pcs.
105.8624 €
20 pcs.
103.5895 €
*incl. VAT plus shipping costs
**Subject to prior sale
Solid State Relay, HD6050, CRYDOM
Solid State Relay, Panel Mount, IP00, 660VAC/50A, DC In, Zero Cross
Features
- Ratings from 25A to 125A @ 48-660 VAC
- SCR output for heavy industrial loads
- Zero voltage or instantaneous turn-on outputs
- UL/CSA/VDE Approved, CE Compliant to EN60950-1
- Improved SEMS screw and washer
- Redesigned housing with anti-rotation barriers
- AC or DC control
- Direct bond copper substrate
- EMC compliant to Level 3
- Direct power lead frame
- Epoxy free design
Technical specifications
| LED display | No | |
| Assembly | PCB mounting | |
| Rated current | 50 A | |
| Switching Mode | zero voltage switching | |
| Voltage V RRM (peak reverse voltage) | 1.2 kV | |
| Control Voltage | 3-32 VDC |
Download
Logistics
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
