HD48125-10 | CRYDOM
Solid state relay, 3-32 VDC, instantaneous switching, 125 A, PCB mounting, HD48125-10
Unit Price (€ / pc.)
211.0703 € *
Available: 0 pcs.
Leadtime: 25 Weeks **
Total Price:
211.07 € *
Price list
Quantity
Price per unit*
1 pcs.
211.0703 €
3 pcs.
204.7276 €
6 pcs.
200.5150 €
12 pcs.
196.2905 €
20 pcs.
192.0779 €
*incl. VAT plus shipping costs
**Subject to prior sale
Solid State Relay, HD48125-10, CRYDOM
Solid State Relay, Panel Mount, IP00, 530VAC/125A, DC In, Instantaneous
Features
- Ratings from 12A to 125A @ 48-530 VAC
- SCR output for heavy industrial loads
- Zero Voltage or instantaneous turn-on outputs
- UL/CSA/VDE Approved, CE Compliant to EN60950-1
- Improved SEMS screw and washer
- Redesigned housing with anti-rotation barriers
- AC or DC control
- Direct bond copper substrate
- EMC compliant to Level 3
- Direct power lead frame
- Epoxy free design
Technical specifications
| LED display | No | |
| Assembly | PCB mounting | |
| Rated current | 125 A | |
| Switching Mode | instantaneous switching | |
| Voltage V RRM (peak reverse voltage) | 1.2 kV | |
| Control Voltage | 3-32 VDC |
Download
Logistics
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
