HD4850-10 | CRYDOM
Solid state relay, 530 VAC, immediate switching, 4-32 VDC, 50 A, screw mounting, HD4850-10
Unit Price (€ / pc.)
114.2519 € *
Available in 5 Days: 134 pcs. - if ordered today
Total Price:
114.25 € *
Price list
Quantity
Price per unit*
1 pcs.
114.2519 €
5 pcs.
108.5518 €
11 pcs.
106.0290 €
20 pcs.
103.7442 €
*incl. VAT plus shipping costs
Subject to prior sale
Solid state relay, HD4850-10, CRYDOM
Solid state relay, Panel Mount, IP00, 530VAC/50A, DC In, Instantaneous.
Features
- SCR output for heavy industrial loads
- UL/CSA/VDE Approved, CE Compliant to EN60950-1
- Improved SEMS screw and washer
- Redesigned housing with anti-rotation barriers
- Direct bond copper substrate
- EMC compliant to Level 3
- Direct power lead frame
- Epoxy free design
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 50 A | |
| Voltage | 4-32 VDC | |
| Control Voltage | 530 VAC | |
| Voltage V RRM (peak reverse voltage) | 1.2 kV | |
| Switching Mode | immediate switching | |
| Assembly | screw mounting | |
| LED display | No |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
