MPY20W1100FA00MSC9 | Wima
MP suppression capacitor, 1 nF, ±20 %, 1 kV (DC), MP, 10 mm, MPY20W1100FA00MSC9
Order No.: 50D3989
EAN: 4099879857934
MPN:
MPY20W1100FA00MSC9
MP 3-Y2 1000 pF 250 VAC
Series: MP 3-Y2
Unit Price (€ / pc.)
0.9639 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
0.96 € *
Price list
Quantity
Price per unit*
1 pcs.
0.9639 €
10 pcs.
0.6902 €
100 pcs.
0.5950 €
500 pcs.
0.5117 €
1000 pcs.
0.4641 €
*incl. VAT plus shipping costs
Subject to prior sale
Film capacitor, MPY20W1100FA00MSC9, WIMA
The MPY20W1100FA00MSC9 is a RFI capacitor connected between phase and neutral or phase and phase conductors. This product is resin impregnated under vacuum and encapsulated with self-extinguishing cast resin,the metallized paper is neither actively nor passively flammable.
Features
- Particularly high reliability against active and passive flammability
- Excellent self-healing as well as high voltage strength
- High degree of interference suppression due to good attenuation and low ESR
- Self-extinguishing epoxy resin, UL 94 V-0, metal foil
- Tinned wire
Applications
- Capacitors connected to the mains between phase or neutral and earthed casing
- By-passing of the basic or supplementary insulation, pulse peak voltage < 5 kV
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Capacity | 1 nF | |
| Rated voltage (DC) | 1 kV | |
| Rated voltage (AC) | 250 V | |
| Tolerance | ±20 % | |
| Dielectric material | MP | |
| Design | radial | |
| Grid | 10 mm | |
| Interference suppression class | Y2 | |
| Number of pins | 2 | |
| Length | 13.5 mm | |
| Width | 4 mm | |
| Height | 8.5 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 110 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85322500 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
