MKP1O131005F00KSSD | Wima
MKP film capacitor, 100 nF, ±10 %, 1 kV (DC), PP, 22.5 mm, MKP1O131005F00KSSD
Unit Price (€ / pc.)
0.7378 € *
Available in 4 Days: 55 pcs. - if ordered today
Film capacitor, MKP1O131005F00KSSD, WIMA
The MKP1O131005F00KSSD is a pulse capacitor that consists of a non-metallized dielectric film and an carrier film metallized on both sides acting as electrode. According to metallization on both sides, this product electrical conductivity is considerably improved and the contact surface between the electrodes and the schoopage layer is doubled.
Features
- Pulse duty construction
- Self-healing
- Very low dissipation factor
- Negative capacitance change versus temperature
Applications
- Switch mode power supplies
- TV and monitor sets
- Lighting
- Audio/video equipment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| min. operating temperature | -55 °C | |
| Grid | 22.5 mm | |
| Tolerance | ±10 % | |
| Rated voltage (DC) | 1 kV | |
| max. operating temperature | 105 °C | |
| Width | 8.5 mm | |
| Capacity | 100 nF | |
| Dielectric material | PP | |
| Rated voltage (AC) | 600 V | |
| Length | 26.5 mm | |
| Number of pins | 2 | |
| Height | 18.5 mm | |
| Design | radial |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322500 |
| Original Packaging | Bulk with 500 pieces |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
