FKP1J024705H00MD00 | Wima
FKP film capacitor, 47 nF, ±20 %, 630 V (DC), PP, 22.5 mm, FKP1J024705H00MD00
Unit Price (€ / pc.)
1.2138 € *
Available: 0 pcs.
Available in 4 Days: 5,400 pcs.
Leadtime: 1 Week **
Film capacitor, FKP1J024705H00MD00, WIMA
The FKP1J024705H00MD00 is a pulse capacitor that was developed for extremly high pulse loads. This product has an internal series connection, the metal foil electrodes being combined with a floating electrode metallized on both sides. The metal foil electrodes are safely contacted on both sides of the end surfaces.
Features
- Self-healing
- Internal series connection
- Extremely high pulse duty
- Very low dissipation factor
- Negative capacitance change versus temperature
Applications
- Switch mode power supplies
- Converter in drives and power electronics
- Deflection systems in monitors and TV-sets
- Electronic ballasts
Technical specifications
| Number of pins | 2 | |
| Design | radial | |
| Width | 10.5 mm | |
| Dielectric material | PP | |
| Height | 20.5 mm | |
| Capacity | 47 nF | |
| Length | 26.5 mm | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -55 °C | |
| Rated voltage (AC) | 400 V | |
| Rated voltage (DC) | 630 V | |
| Grid | 22.5 mm | |
| Tolerance | ±20 % |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85322500 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
