2865290000 | Weidmüller
Pin header, 11 pole, pitch 7.62 mm, straight, green, 2865290000
Order No.: 50P0533
EAN: 4064675600787
MPN:
2865290000
SL 7.62/11/180B 3.2SN GN BX
Unit Price (€ / pc.)
4.0341 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
4.03 € *
Price list
Quantity
Price per unit*
1 pcs.
4.0341 €
10 pcs.
3.7485 €
50 pcs.
3.4986 €
100 pcs.
3.2844 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB plug-in connector, 2865290000, Weidmüller
PCB plug-in connector, THT solder connection, Cu-alloy, Pale green.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 7.62 mm | |
| Contact type | pin | |
| Connection | solder connection | |
| Rated voltage | 800 V | |
| Orientation | straight | |
| Number of rows | 1 | |
| Type of locking | No | |
| Pin number | 11 pole | |
| Colour | green | |
| Version | pin header | |
| Rated current | 17 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85472000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
