783-623 | WAGO
1-wire potential equalization terminal, cage clamp, 0.2-16 mm², 1 pole, 68 A, 6 kV, gray, 783-623
1-conductor power distribution disconnect terminal block, 783-623, WAGO
This power distribution disconnect terminal block is designed for seamless electrical installation. Conductors should only be connected to this power distribution disconnect terminal block if their strip length is between 16 mm and 17 mm. This product features a conductor terminal and utilizes CAGE CLAMP. Our tried-and-tested universal connection, CAGE CLAMP, is industry-leading when it comes to connection technology and electrical interconnections. This power distribution disconnect terminal block is suitable for a conductor cross section ranging from 0.2 mm² to 16 mm². It has one level. A single potential can be connected using one clamping point. The gray housing is made of polyamide (PA66) for insulation. This installation rail-mount terminal block is mounted using a DIN-35 rail.
| Filter | Property | Value |
|---|---|---|
| Version | 1-wire potential equalization terminal | |
| Pin number | 1 pole | |
| Rated Voltage | 400 V | |
| Cable cross-section | 0.2-16 mm² | |
| Rated surge voltage | 6 kV | |
| Number of terminals | 1 | |
| Height | 88.5 mm | |
| Width | 12 mm | |
| Connection | cage clamp | |
| Rated current | 68 A | |
| Colour | gray | |
| Degree of soiling | 3 | |
| AWG cross-section | AWG 24 to 6 |
| Property | Value |
|---|---|
| Customs tariff number | 85369010 |
| Country of origin | PL |
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
