TPC 120-124 | TRACO POWER
Power supply, 24 to 28.8 VDC, 5 A, 120 W, TPC 120-124
Unit Price (€ / pc.)
111.0627 € *
Available in 7 Days: 175 pcs. - if ordered today
Industrial Power Supply, TPC 120-124, TRACO POWER
The TPC 120-124 is lightweight DIN-rail power supply with an excellent price/performance ratio. It consumes sparse standby power, and operates with high efficiency.
Features
- Low ripple and noise
- Short circuit and overload protection
- Adjustable output voltage
- Power good signal
Applications
- Industrial, office and residential environments
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Output current | 5 A | |
| Output voltage DC | 24 to 28.8 VDC | |
| Width | 72 mm | |
| Power | 120 W | |
| Input voltage AC | 85-264 VAC, 90-375 VDC | |
| Number of outputs | 1 | |
| Depth | 90 mm | |
| efficiency | 87 % | |
| Degree of protection (IP) | IP20 | |
| Height | 110 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
