TES 2N-2411 | TRACO POWER
DC converter, 18-36 VDC, 2 W, 1 output, 5 VDC, 77 % efficiency, TES 2N-2411
Unit Price (€ / pc.)
23.4311 € *
Available in 7 Days: 3,300 pcs. - if ordered today
Total Price:
23.43 € *
Price list
Quantity
Price per unit*
1 pcs.
23.4311 €
10 pcs.
21.0868 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC Converter, TES 2N-2411, TRACO POWER
The TES 2N-2411 is high performance 2W DC/DC converter module featuring a 2:1 input voltage range. It comes in a low profile SMD package which requires just 3 cm² space on the PCB. A high efficiency allows an operating temperature range of -40°C to +85°C.
Features
- Short circuit and over voltage protection
- Bears washing process
Applications
- Battery operated equipment
- Instrumentation
- Communication and industrial electronics
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 400 mA | |
| Output voltage DC | 5 VDC | |
| Input voltage AC | 18-36 VDC | |
| Power | 2 W | |
| efficiency | 77 % | |
| Design | SMD | |
| Isolation voltage | 1.5 kV | |
| Length | 24 mm | |
| Width | 13.7 mm | |
| Height | 9 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Original Packaging | Bar with 10 pieces |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
