0001.2502 | SCHURTER

Name: Microfuses 5 x 20 mm, 630 mA, T, 300 V (DC), 250 V (AC), 1.5 kA breaking capacity, 0001.2502
Brand: SCHURTER
SKU: 43G302
Price: 0.32 EUR
Availability: OutOfStock

Microfuses 5 x 20 mm, 630 mA, T, 300 V (DC), 250 V (AC), 1.5 kA breaking capacity, 0001.2502

Order No.: 43G302

EAN: 4099889088045

MPN:

0001.2502

Series: SPT 5x20

Image may differ

Key Specification:

Version microfuses

Design 5 x 20 mm

Enclosure ceramic tube

Rated current 630 mA

Tripping characteristics T

Show 16 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.3213 € *

Available: 0 pcs.

Leadtime: 17 Weeks **

Add to Cart

Total Price:

0.32 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Micro fuse, 0001.2502,SCHURTER

The 0001.2502 is a time-lag fuse that allows for a temporary current surge without going above the fuse's current rating. Because of this time delay fuses are most commonly used to protect motor circuits.

Features

Material ceramic tube
Material endcaps copper alloy nickel-plated
High breaking capacity
Cartridge model

Applications

Primary protection in equipment
Power supply adapter
SMPS (Switching Mode Power Supply) for TV's and DVD's

Download

Technical Data Sheet - EN Technical Data Sheet

Declaration of Conformity - EN Declaration of Conformity

Technical Data Sheet - DE Technical Data Sheet

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	CN
Customs tariff number	85361010
Original Packaging	Carton with 10 pieces

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes

Accessory

Fuse holder, 5 x 20 mm, 10 A, 250 V, snap-in, 3101.0030

Order No.:

46G5820

Manufacturer SKU:

3101.0030

Available: 265 pcs. Leadtime: 2 Weeks **

2.06 € per pc. *
