XB5FJ21 | Schneider Electric
Toggle switch, 2 positions, unlit, latching, 1 Form A (N/O), waistband round, black, front ring gray, 90°, mounting Ø 30.5 mm, XB5FJ21
Unit Price (€ / pc.)
20.2776 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
20.28 € *
Price list
Quantity
Price per unit*
1 pcs.
20.2776 €
3 pcs.
19.3970 €
5 pcs.
18.3260 €
10 pcs.
17.3740 €
*incl. VAT plus shipping costs
Subject to prior sale
Selector switch, XB5FJ21, Schneider Electric
Selector switch flush mounted, Harmony XB5, plastic, black, 30mm, long handle, 2 positions, stay put, 1NO.
Features
- Quick and easy assembly and disassembly
- Robustness to withstand harsh environments
- With various types of connection: screw clamp, connector, Faston connector, spring terminal, or printed circuit board
- A wide choice of contact blocks for general purposes or specific applications (low current, standard)
- Excellent mechanical connection with operator head
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | screw connection | |
| Actuator colour | black | |
| Latching switching function | 1 Form A (N/O) | |
| Protection class | IP66/IP67/IP69/IP69K | |
| Collar shape of the front frame | round | |
| Front ring colour | gray | |
| Version | 2 positions | |
| Contact function | latching | |
| Product type | toggle switch | |
| Rotation angle | 90° | |
| can be illuminated | No | |
| Installation diameter | 30.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
