1243828 | Phoenix Contact
Jack, M23, 6 pole, solder connection, screw locking, straight, 1243828
Unit Price (€ / pc.)
23.5263 € *
Standard delivery time from the manufacturer is: 5 Weeks
Total Price:
23.53 € *
Price list
Quantity
Price per unit*
1 pcs.
23.5263 €
10 pcs.
22.0507 €
25 pcs.
20.7536 €
50 pcs.
19.5993 €
*incl. VAT plus shipping costs
Subject to prior sale
Cable connector, 1243828, Phoenix Contact
M23, Cable connector, Series: CA, straight, shielded: yes, Screw locking mechanism, number of positions: 6, Drehsinn: Standard, contact connection type: Socket, Lötanschluss, cable diameter range: 3 mm - 14,5 mm, Kodierung: N, Item is lead-free in accordance with RoHS II without Exemption 6c (Pb < 0.1 %).
Features
- Safe use in the field, thanks to high degree of protection
- Connector for flexible on-site assembly
- Consistent EMC protection for reliable transmission of signals
- Solder connection: proven connection technology for various litz wires
Technical specifications
| Pin number | 6 pole | |
| Degree of protection (IP) | IP67 | |
| Assembly | cable assembly | |
| Orientation | straight | |
| Coding | N | |
| Product type | jack | |
| Type of locking | screw locking | |
| Contact connection | solder connection | |
| Thread size | M23 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| SVHC free | No |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
