1457908 | Phoenix Contact
Valve connector, DIN shape A, 5 pole, 24 V, 0.25-1.5 mm², 1457908
Unit Price (€ / pc.)
18.5997 € *
Available: 0 pcs.
Leadtime: 2 Weeks **
Valve connector, 1457908, Phoenix Contact
Valve connector, 5-pole, valve connector AD (pressure switch), with 2 LEDs, screw connection, cable gland M16, cable outer diameter 6-8 mm
Technical specifications
| Version | DIN shape A | |
| LED display | Yes | |
| Cable cross-section | 0.25-1.5 mm² | |
| Rated voltage | 24 V | |
| Pin number | 5 pole | |
| Degree of protection (IP) | IP65 | |
| Type of locking | central screw |
Download
Logistics
| Country of origin | HU |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
