1452246 | Phoenix Contact

Valve connector, DIN shape BI, 3 pole, 110 V, 0.25-1.5 mm², 1452246

Order No.: 61P9493
EAN: 4046356536417
MPN:
1452246
SACC-VB-3CON-M16/BI-1L-SV 110V
Series: SACC
1452246 Phoenix Contact DIN Valve Connectors Image 1
1452246 Phoenix Contact DIN Valve Connectors Image 2
Image may differ
Unit Price (€ / pc.)
8.4133 € *
Available in 10 days: 104 pcs. - if ordered today
Total Price:
8.41 € *
Price list
Quantity
Price per unit*
1 pcs.
8.4133 €
5 pcs.
7.9849 €
10 pcs.
7.6041 €
15 pcs.
7.1519 €
20 pcs.
6.7354 €
*incl. VAT plus shipping costs
Subject to prior sale

Valve connector, 1452246, Phoenix Contact

Valve connector, 3-pole, valve connector BI (11 mm), with 1 LED, wired with varistor, screw connection, cable gland M16, cable outer diameter 6-8 mm.

Technical specifications
Version DIN shape BI
Cable cross-section 0.25-1.5 mm²
Pin number 3 pole
Rated voltage 110 V
Degree of protection (IP) IP65
Wiring varistor
LED display Yes
Type of locking central screw
Logistics
Country of origin HU
Customs tariff number 85366990
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
