1452165 | Phoenix Contact

Valve connector, DIN shape A, 3 pole, 230 V, 0.25-1.5 mm², 1452165

Order No.: 61P9484
EAN: 4046356536332
MPN:
1452165
SACC-VB-3CON-M16/A-1L-SV 230V
Series: SACC
1452165 Phoenix Contact DIN Valve Connectors Image 1
1452165 Phoenix Contact DIN Valve Connectors Image 2
Image may differ
Unit Price (€ / pc.)
12.6616 € *
Available in 10 days: 20 pcs. - if ordered today
Total Price:
12.66 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
12.6616 €

Valve connector, 1452165, Phoenix Contact

Valve connector, 3-pole, valve connector A, with 1 LED, wired with varistor, screw connection, cable gland M16, cable outer diameter 6-8 mm.

Technical specifications
Version DIN shape A
Cable cross-section 0.25-1.5 mm²
Pin number 3 pole
Rated voltage 230 V
Degree of protection (IP) IP65
Wiring varistor
LED display Yes
Type of locking central screw
Logistics
Customs tariff number 85366990
Country of origin HU
Compliance
SVHC free No
Substance description Lead
RoHS conform Yes
Date of RoHS guidelines 3/31/15
