ALE12F06T | Panasonic

Name: Relay, 1 Form A (N/O), 6 V (DC), 90 Ω, 16 A, 277 V (AC), monostable, ALE12F06T
Brand: Panasonic
SKU: 34G5128
Price: 2.07 EUR
Availability: OutOfStock

Relay, 1 Form A (N/O), 6 V (DC), 90 Ω, 16 A, 277 V (AC), monostable, ALE12F06T

Order No.: 34G5128

EAN: 4099889401264

MPN:

ALE12F06T

ALE12F06

Series: LE

Image may differ

Key Specification:

Contact type 1 Form A (N/O)

switching current 16 A

Coil voltage (DC) 6 V

Coil resistance 90 Ω

Show 26 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

2.0706 € *

Available: 0 pcs.

Leadtime: On Request **

Add to Cart

Total Price:

2.07 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Power relay, ALE12F06T, PANASONIC

Features

Supports magnetron and heater loads
Excellent heat resistance
High insulation resistance
Low operating power

Applications

Microwave ovens
Refrigerators
OA equipment

Technical specifications

	Connection	PCB connection
	Contact type	1 Form A (N/O)
	Contact material	AgSnO2
	Switching Voltage (AC)	277 V
	switching current	16 A
	Coil voltage (DC)	6 V
	Coil type	monostable
	Coil resistance	90 Ω

Show similar products 0

Download

Technical Data Sheet - EN Technical Data Sheet

Declaration of Conformity - EN Declaration of Conformity

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	TH
Customs tariff number	85364900

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes
