HDR-15-24 | MEAN WELL

Power supply, 21.6 to 29 VDC, 630 mA, 15 W, HDR-15-24

Order No.: 62C1514
EAN: 4099891285777
MPN:
HDR-15-24
Series: HDR-15
MEAN WELL
default L
Image may differ
Unit Price (€ / pc.)
25.6921 € *
Available: 76 pcs.
Next delivery: 6 pcs. on 2024-04-26
Leadtime: 3 Weeks **
Total Price:
25.69 € *
Price list
Quantity
Price per unit*
1 pcs.
25.6921 €
10 pcs.
22.6100 €
50 pcs.
21.0749 €
150 pcs.
20.1467 €
500 pcs.
19.1233 €
*incl. VAT plus shipping costs
**Subject to prior sale

Power supply, HDR-15-24, MEAN WELL

HDR-15-24 is an economical, ultra-slim 15W DIN rail power supply. The housing is 17.5 mm wide, which allows space savings in cabinets. This unit is suitable for the entire input range from 85 VAC to 264 VAC. With a working efficiency of up to 87%, it can operate at an ambient temperature between -30 °C and 70 °C under air convection.

Features

  • Power consumption without load <0.3 W
  • Insulation class II
  • Limited energy source
  • DC output voltage adjustable
  • Protection functions: Short circuit, overload, overvoltage
  • Cooling by free air convection
  • LED indicator for power on

Applications

  • Budgetary control system
  • Building automation
  • Industrial control system
  • Factory automation
  • Electro-mechanical device
Technical specifications
Number of outputs 1
Output voltage DC 21.6 to 29 VDC
Output current 630 mA
Width 17.5 mm
Input voltage AC 85-264 VAC, 120-370 VDC
Height 90 mm
Power 15 W
Depth 54.5 mm
efficiency 86 %
Logistics
Country of origin CN
Customs tariff number 85043180
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
Output current
Output voltage DC
efficiency
Power
Depth
Input voltage AC
Width
Height
Number of outputs
1 item in 4 variations
*incl. VAT plus shipping costs
Item description
Total
Price list
Output current
Output voltage DC
efficiency
Power
Depth
Input voltage AC
Width
Height
Number of outputs
Power supply, 10.8 to 13.8 VDC, 1.25 A, 15 W, HDR-15-12
Order No.:
 62C1512
Manufacturer:
 MEAN WELL
Manufacturer SKU:
 HDR-15-12
Available: 11 pcs. Leadtime: 3 Weeks **
Total Price: 25.69 € *
1 pcs.
25.6921 €
10 pcs.
22.6100 €
50 pcs.
21.0749 €
150 pcs.
20.1467 €
500 pcs.
19.1233 €
1.25 A
10.8 to 13.8 VDC
85 %
15 W
54.5 mm
85-264 VAC, 120-370 VDC
17.5 mm
90 mm
1
Power supply, 21.6 to 29 VDC, 630 mA, 15 W, HDR-15-24
Order No.:
 62C1514
Manufacturer:
 MEAN WELL
Manufacturer SKU:
 HDR-15-24
Available: 76 pcs. Leadtime: 3 Weeks ** Next delivery: 6 pcs. on 2024-04-26
Total Price: 25.69 € *
1 pcs.
25.6921 €
10 pcs.
22.6100 €
50 pcs.
21.0749 €
150 pcs.
20.1467 €
500 pcs.
19.1233 €
630 mA
21.6 to 29 VDC
86 %
15 W
54.5 mm
85-264 VAC, 120-370 VDC
17.5 mm
90 mm
1
Power supply, 13.5 to 18 VDC, 1 A, 15 W, HDR-15-15
Order No.:
 62C1513
Manufacturer:
 MEAN WELL
Manufacturer SKU:
 HDR-15-15
Available: 0 pcs. Leadtime: On Request **
Total Price: 21.02 € *
1 pcs.
21.0154 €
10 pcs.
18.4926 €
100 pcs.
16.2316 €
1 A
13.5 to 18 VDC
85.5 %
15 W
54.5 mm
85-264 VAC, 120-370 VDC
17.5 mm
90 mm
1
Power supply, 4.5 to 5.5 VDC, 2.4 A, 12 W, HDR-15-5
Order No.:
 62C1516
Manufacturer:
 MEAN WELL
Manufacturer SKU:
 HDR-15-5
Available: 0 pcs. Leadtime: 1 Week **
Total Price: 21.02 € *
1 pcs.
21.0154 €
10 pcs.
18.4926 €
100 pcs.
16.2316 €
2.4 A
4.5 to 5.5 VDC
80 %
12 W
54.5 mm
85-264 VAC, 120-370 VDC
17.5 mm
90 mm
1
