HDR-15-12 | MEAN WELL

Power supply, 10.8 to 13.8 VDC, 1.25 A, 15 W, HDR-15-12

Order No.:  62C1512
MPN:
HDR-15-12
Series:  HDR-15
EAN: 4099891285753
MEAN WELL
default L
default S
Images may differ
Unit Price (€ / pc.)
25.6921 € *
Available: 8 pcs.
Next delivery: 3 pcs. on 2024-03-29
Leadtime: 3 Weeks **
Total Price:
25.69 € *
Quantity
Price per unit*
1 pcs.
25.6921 €
10 pcs.
22.6100 €
50 pcs.
21.0749 €
150 pcs.
20.1467 €
500 pcs.
19.1233 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description

Power supply, HDR-15-12, MEAN WELL

HDR-15-12 is an economical, ultra-slim 15 W DIN rail power supply. The housing is 17.5 mm wide, which allows space savings in the control cabinet. This device is suitable for the entire input range from 85 VAC to 264 VAC. With an efficiency of up to 87%, it can operate at an ambient temperature between -30°C and 70°C under air convection.

Features

  • Power consumption without load <0.3 W
  • Insulation class II
  • Limited energy source
  • DC output voltage adjustable
  • Protection functions: Short circuit, overload, overvoltage
  • Cooling by free air convection
  • LED indicator for power on

Applications

  • Budgetary control system
  • Building automation
  • Industrial control system
  • Factory automation
  • Electro-mechanical device
Technical specifications
Number of outputs 1
Output voltage DC 10.8 to 13.8 VDC
Output current 1.25 A
Width 17.5 mm
Input voltage AC 85-264 VAC, 120-370 VDC
Height 90 mm
Power 15 W
Depth 54.5 mm
efficiency 85 %
Show similar products (0)
Logistics
Country of origin CN
Customs tariff number 85043180
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
Search results: 1 item in 4 variations
*incl. VAT plus shipping costs
Item description
Total
Price list
Availability
Output current
Output voltage DC
efficiency
Power
Depth
Input voltage AC
Width
Height
Number of outputs
Power supply, 21.6 to 29 VDC, 630 mA, 15 W, HDR-15-24
Order No.:
 62C1514
Manufacturer:
 MEAN WELL
Manufacturer SKU:
 HDR-15-24
Total Price: 25.69 € *
1 pcs.
25.6921 €
10 pcs.
22.6100 €
50 pcs.
21.0749 €
150 pcs.
20.1467 €
500 pcs.
19.1233 €
Available: 79 pcs.
Next delivery: 6 pcs. on 2024-04-26
Leadtime: 3 Weeks **
630 mA
21.6 to 29 VDC
86 %
15 W
54.5 mm
85-264 VAC, 120-370 VDC
17.5 mm
90 mm
1
Power supply, 10.8 to 13.8 VDC, 1.25 A, 15 W, HDR-15-12
Order No.:
 62C1512
Manufacturer:
 MEAN WELL
Manufacturer SKU:
 HDR-15-12
Total Price: 25.69 € *
1 pcs.
25.6921 €
10 pcs.
22.6100 €
50 pcs.
21.0749 €
150 pcs.
20.1467 €
500 pcs.
19.1233 €
Available: 8 pcs.
Next delivery: 3 pcs. on 2024-03-29
Leadtime: 3 Weeks **
1.25 A
10.8 to 13.8 VDC
85 %
15 W
54.5 mm
85-264 VAC, 120-370 VDC
17.5 mm
90 mm
1
Power supply, 4.5 to 5.5 VDC, 2.4 A, 12 W, HDR-15-5
Order No.:
 62C1516
Manufacturer:
 MEAN WELL
Manufacturer SKU:
 HDR-15-5
Total Price: 21.02 € *
1 pcs.
21.0154 €
10 pcs.
18.4926 €
100 pcs.
16.2316 €
Available: 0 pcs.
Leadtime: On Request **
2.4 A
4.5 to 5.5 VDC
80 %
12 W
54.5 mm
85-264 VAC, 120-370 VDC
17.5 mm
90 mm
1
Power supply, 13.5 to 18 VDC, 1 A, 15 W, HDR-15-15
Order No.:
 62C1513
Manufacturer:
 MEAN WELL
Manufacturer SKU:
 HDR-15-15
Total Price: 21.02 € *
1 pcs.
21.0154 €
10 pcs.
18.4926 €
100 pcs.
16.2316 €
Available: 0 pcs.
Leadtime: On Request **
1 A
13.5 to 18 VDC
85.5 %
15 W
54.5 mm
85-264 VAC, 120-370 VDC
17.5 mm
90 mm
1
