Smart High Side Power Switch BTS4141N

default S
default L
Total price
(0.00 € * / pcs.)
0.00 €
Currently not in stock, we will order for you
Quantity
Price per unit*
0 pcs.
0.00 €
*incl. VAT plus shipping costs
Show 3 variants
Description

Product by Infineon Technologies at Bürklin Elektronik

High side switch, BTS4141N, Infineon Technologies

The BTS4141N is a vertical power FET with charge pump, ground referenced CMOS compatible input and diagnostic feedback, monolithically integrated in smart SIPMOS technology.

Features

  • Overload protection
  • Current limitation
  • Short circuit protection
  • Overvoltage protection (including load dump)
  • Reverse battery protection with external resistor
  • Undervoltage shutdown with auto-restart and hysteresis
  • ESD protected

Applications

  • Compatible power switch for 12 V and 24 V DC grounded loads
  • All types of resistive, inductive and capacitive loads
  • Replaces electromechanical relays, fuses and discrete circuits
Technical specifications
Number of channels 1
Version N channel
drain-source on resistance RDS (on) @ Tj = 25°C max 0.2 Ω
Enclosure SOT-223
max. Voltage 45 V
Max. current 0.7 A
max. operating temperature 125 °C
min. operating temperature -40 °C
Assembly SMD
