BFR92WE6327XT | Infineon Technologies

Name: Bipolar junction transistor, NPN, 45 mA, 15 V, SMD, SOT-323, BFR92WE6327XT
Brand: Infineon Technologies
SKU: 16S9612
Price: 0.20 EUR
Availability: InStock

Bipolar junction transistor, NPN, 45 mA, 15 V, SMD, SOT-323, BFR92WE6327XT

Order No.: 16S9612

MPN:

BFR92WE6327XT

Series: BFR

EAN: 4099879028990

Images may differ

Key Specification:

Assembly SMD

Enclosure SOT-323

Version NPN

Collector current 45 mA

Show 3 variants

Technical specifications Download Datasheet

Discontinued

Unit Price (€ / pc.)

0.1999 € *

Available: 279 pcs.

Leadtime: On Request **

Total Price:

5.00 € *

Quantity

Price per unit*

25 pcs.

0.1999 €

125 pcs.

0.1737 €

500 pcs.

0.1535 €

2000 pcs.

0.1404 €

5000 pcs.

0.1309 €

*incl. VAT plus shipping costs

**Subject to prior sale

Add to comparison list Print

Description

Bipolar transistor, BFR92WE6327XT, Infineon Technologies

The BFR92WE6327XT is a low noise silicon bipolar RF transistor that is used for broadband amplifiers and fast non-saturated switches.

Features

Low current gain
High collector-emitter breakdown voltage
Low noise
Pb-free and RoHs-compliant

Applications

For broadband amplifiers
For fast non-saturated switches at collector currents

Technical specifications

	Version	NPN
	Enclosure	SOT-323
	max. operating temperature	150 °C
	max.voltage between collector and base Vcbo	20 V
	max.voltage between collector and emitter Vceo	15 V
	min. operating temperature	-55 °C
	Assembly	SMD
	Rated current	30 mA
	Transit frequency fTmin	5 GHz
	Power dissipation	0.28 W
	Collector current	45 mA
	Max DC amplification	140 mA
	Min DC gain	70 mA
