10022733 | Fischer Elektronik

Extruded heatsink, 1000 x 400 x 40 mm, 0.58 to 0.31 K/W, natural aluminum

Order No.: 65B936
EAN: 4099889473858
MPN:
10022733
SK 93 1000 AL
Fischer Elektronik
default L
Image may differ
Print
Key Specification:
Min. heat resistance 0.31 K/W
Max. heat resistance 0.58 K/W
Length 1000 mm
Width 400 mm
Download Datasheet Technical specifications
Unit Price (€ / pc.)
399.3521 € *
Available: 0 pcs.
Leadtime: 5 Weeks **
Add to Cart
Total Price:
399.35 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
399.3521 €
Description
Technical specifications
Download
Logistics
Compliance

Standard extruded heatsink, 10022733, Fischer Elektronik

Standard extruded heatsink with thermal resistance: 0.58-0.31 K/W, Surface: raw degreased aluminium (by the metre raw aluminium).
Technical specifications
Version profile heatsink
Width 400 mm
Height 40 mm
Length 1000 mm
Material die-cast aluminum
Max. heat resistance 0.58 K/W
Min. heat resistance 0.31 K/W
Surface type natural aluminum
Show similar products 0
Logistics
Country of origin DE
Customs tariff number 76042990
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
