10019974 | Fischer Elektronik

Extruded heatsink, 1000 x 40 x 8 mm, 13.9 to 4.9 K/W, natural aluminum

Order No.: 65B852
EAN: 4099889473124
MPN:
10019974
SK 420 1000 AL
Fischer Elektronik
default L
Image may differ
Print
Key Specification:
Min. heat resistance 4.9 K/W
Max. heat resistance 13.9 K/W
Length 1000 mm
Width 40 mm
Download Datasheet Technical specifications
Unit Price (€ / pc.)
39.8293 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Add to Cart
Total Price:
39.83 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
39.8293 €
Description
Technical specifications
Download
Logistics
Compliance

Standard extruded heatsink, 10019974, Fischer Elektronik

Standard extruded heatsink with thermal resistance: 13.9-4.9 K/W, Surafce: black anodised.
Technical specifications
Version profile heatsink
Width 40 mm
Height 8 mm
Length 1000 mm
Material aluminum
Max. heat resistance 13.9 K/W
Min. heat resistance 4.9 K/W
Surface type natural aluminum
Show similar products 0
Logistics
Country of origin DE
Customs tariff number 76042990
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
