106-40066 | ept
Female connector, type D, 32 pole, a-c, pitch 5.08 mm, solder lug, straight, tin-plated, 106-40066
Order No.: 52F7168
EAN: 4099891021597
MPN:
106-40066
Unit Price (€ / pc.)
6.0571 € *
Available: 50 pcs.
Next delivery: 25 pcs. on 2024-05-10
Leadtime: 5 Weeks **
Total Price:
6.06 € *
Price list
Quantity
Price per unit*
1 pcs.
6.0571 €
10 pcs.
5.3193 €
100 pcs.
4.6767 €
*incl. VAT plus shipping costs
**Subject to prior sale
Female connector DIN 41612/IEC 60603-2, type ept.
Requirements class 2; Quality class to DIN EN 60603-2: II/400 insertion/removal cycles. Insulation resistance: min. 1000 Gohm. Spring contact: double, double spring, two-sided. Insulator: PBTP, glass fiber-reinforced (UL 94 V-0), PC, glass fiber-reinforced (UL 94 V-1). Operating temperatures: –55 to +125 °C (design H = –65 to +125 °C). Certifications: UL.
Straight feFemale connector D with solder lugs.
Technical attributes (type, number of poles, contact row assignments, overall length): 106-40066, 32-pole, a-c, 5.5 mm, 94.9 mm
Technical specifications
| Performance level | 2 | |
| Connection | solder lug | |
| Design | D | |
| Contact type | socket | |
| contact surface | tin-plated | |
| Contact row assignment | a-c | |
| Rated current | 5.6 A | |
| Orientation | straight | |
| Pin number | 32 pole | |
| Grid | 5.08 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85389099 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
