HHXC350ARA470MF61G | Chemi-Con
Polymer hybrid aluminum electrolytic capacitor, SMD, 47 µF, 35 V, ±20 %, HHXC350ARA470MF61G
Unit Price (€ / pc.)
0.9163 € *
Available: 247 pcs.
Next delivery: 1,000 pcs. on 2025-12-08
Total Price:
0.92 € *
Price list
Quantity
Price per unit*
1 pcs.
0.9163 €
10 pcs.
0.5950 €
100 pcs.
0.4522 €
500 pcs.
0.3689 €
1000 pcs.
0.3332 €
*incl. VAT plus shipping costs
Subject to prior sale
Conductive polymer hybrid, HHXC350ARA470MF61G, Chemi-Con
The HHXC350ARA470MF61G is a conductive polymer hybrid aluminum electrolytic capacitor with high reliability and high voltage realized by hybrid electrolyte.
For high temperature and high reliability applications like automotive equipment, base station equipment, etc.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| diameter | 6.3 mm | |
| Ripple current | 900 mA | |
| max. operating temperature | 125 °C | |
| Rated voltage (DC) | 35 V | |
| Length | 5.8 mm | |
| Capacity | 47 µF | |
| Design | SMD | |
| min. operating temperature | -55 °C | |
| Tolerance | ±20 % | |
| ESR (Equivalent Series Resistance) | 60 mΩ |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | JP |
| Original Packaging | Reel with 1,000 pieces |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
