MPI002/28/BL | BULGIN
Pushbutton, 2 pole, silver, illuminated (blue), 0.05 A/24 V, mounting Ø 19.2 mm, IP66, MPI002/28/BL
Unit Price (€ / pc.)
29.7738 € *
Available: 128 pcs.
Leadtime: 14 Weeks **
Total Price:
29.77 € *
Price list
Quantity
Price per unit*
1 pcs.
29.7738 €
5 pcs.
27.9769 €
15 pcs.
26.9059 €
50 pcs.
25.7159 €
150 pcs.
24.6568 €
*incl. VAT plus shipping costs
**Subject to prior sale
Vandal resistant pushbutton, degree of protection IP 66, illuminated, type Bulgin MPI00.
Single-pole NO, screw terminals, made of stainless steel; Panel mount diameter: 19 mm. Switching power: 24 VDC/50 mA. Contact resistance: max. 100 mohm. Actuating force: 12 N. Degree of protection: IP 66. Operating temperatures: –30 to +70 °C.
With ring illumination, 2.8 mm tab terminals, type MPI002.
Type: MPI002/28/BL, pushbutton, blue
Technical specifications
| Connection | quick connection | |
| Design | round | |
| Printed | No | |
| illuminated | Yes | |
| Installation diameter | 19.2 mm | |
| Actuator colour | silver | |
| Farbe der Beleuchtung | blue | |
| contact surface | gold-plated | |
| Pin number | 2 pole | |
| Latching switching function | groping | |
| Breaking capacity | 0.05 A/24 V | |
| Protection class | IP66 | |
| Vandal-proof | Yes |
Download
Logistics
| Country of origin | TN |
| Customs tariff number | 85365080 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
