IPR3SAD2 | APEM
Vandal-proof pushbutton, 1 pole, black, unlit , 5 A/28 VDC, mounting Ø 13.6 mm, IP67, IPR3SAD2
Unit Price (€ / pc.)
12.7568 € *
Available: 646 pcs.
Total Price:
12.76 € *
Price list
Quantity
Price per unit*
1 pcs.
12.7568 €
10 pcs.
11.2217 €
25 pcs.
10.4601 €
50 pcs.
9.9960 €
100 pcs.
9.4962 €
*incl. VAT plus shipping costs
Subject to prior sale
Panel switch, IPR3SAD2, APEM
The IPR3SAD2 panel switch, also known as a pushbutton switch, is a versatile and reliable control solution. With its round curved actuator design, it offers a comfortable and intuitive user experience. The electrical functions of this switch are normally open (NO), allowing for easy and efficient circuit control. The contacts of the IPR3SAD2 are made of silver goldplated standard materials, ensuring superior conductivity and durability. Whether you need to control lights, appliances, or other electrical devices, the IPR3SAD2 Panel Switch is the perfect choice.
Features
- Tactile feedback
- Wide variety of configurations
- Flat round actuator for optional marking
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | groping | |
| Pin number | 1 pole | |
| Protection class | IP67 | |
| Vandal-proof | Yes | |
| Printed | No | |
| Connection | solder connection | |
| illuminated | No | |
| Breaking capacity | 5 A/28 VDC | |
| Installation diameter | 13.6 mm | |
| Design | round | |
| contact surface | gold-plated | |
| Actuator colour | black | |
| Wall thickness | 1.5-4 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | FR |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
