DB1C-A1AA | ZF Switches and Sensors
Subminiature snap-action switch, On-Off, solder connection, pin plunger, 1.5 N, 5 A/125 VAC, 1 A/48 VDC, IP50, DB1C-A1AA
Unit Price (€ / pc.)
0.9044 € *
Standard delivery time from the manufacturer is: 19 Weeks
Total Price:
1,085.28 € *
Price list
Quantity
Price per unit*
1200 pcs.
0.9044 €
2400 pcs.
0.8449 €
3600 pcs.
0.8092 €
4800 pcs.
0.7735 €
*incl. VAT plus shipping costs
Subject to prior sale
Subminiature Snap Switch, DB1C-A1AA, ZF Switches and Sensors
Single pole subminiature snap switch
Features
- Precise snap action switch
- Long life coil spring mechanism
- Different mounting options (location posts, mounting holes)
- Protection class: IP50
- Various aux actuators (also for retrofitting, two mounting points)
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | On-Off | |
| Actuator | pin plunger | |
| actuating force | 1.5 N | |
| Switching point | 8.4 mm ±0.3 mm | |
| Connection | solder connection | |
| Design | straight | |
| Shell Material | PET | |
| Breaking capacity | 5 A/125 VAC, 1 A/48 VDC | |
| Protection class | IP50 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | GB |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
