74437356022 | Würth Elektronik eiSos

Power choke, SMD 8030, 2.2 µH, 8.5 A, 74437356022

Order No.: 73D1220
EAN: 4099889286489
MPN:
74437356022
Series: WE-LHMI
Würth Elektronik eiSos
default L
Image may differ
Print
Key Specification:
Version power inductor
Inductance 2.2 µH
DC current 8.5 A
Tolerance ±20 %
DC resistance 20.3 mΩ
Show 13 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
2.2729 € *
Available: 50 pcs.
Available in 5 Days: 199 pcs.
Leadtime: 1 Week **
Total Price:
2.27 € *
Price list
Quantity
Price per unit*
1 pcs.
2.2729 €
10 pcs.
2.1420 €
50 pcs.
2.0706 €
100 pcs.
1.8802 €
500 pcs.
1.7136 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

Characteristics

  • Compact Design
  • Handles high transient current spikes
  • High current capability and handles high transient current spikes
  • Magnetical shielded
  • No acoustic noise and no leakage field
  • Operating temperature -40°C to +125°C

Application:

  • DC/DC Converters for high current power supplies
  • DC/DC Converters for Field Programmable Gate Arrays (FPGA)
  • POL Converters
  • Portable power like PDA, digital camera
  • Mainboards/ graphic cards
  • CPU/ RAM
  • Battery powered devices
Technical specifications
Version power inductor
Design SMD 8030
Width 8.5 mm
DC current 8.5 A
DC resistance 20.3 mΩ
Height 3 mm
Inductance 2.2 µH
Length 9.7 mm
Measuring frequency 24 MHz
Tolerance ±20 %
Show similar products 0
Logistics
Country of origin CN
Customs tariff number 85045000
MSL MSL 1
Original Packaging Reel with 1,000 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
1 item in 13 variations
