860040774002 | Würth Elektronik eiSos

Electrolytic capacitor, 47 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm

Order No.: 14D1446
EAN: 4099879140975
MPN:
860040774002
Series: WCAP-ATUL
Würth Elektronik eiSos
default L
Image may differ
Print
Key Specification:
Version polar
Capacity 47 µF
Rated voltage (DC) 63 V
Tolerance ±20 %
Show 16 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
0.3832 € *
Available: 36 pcs.
Available in 5 Days: 10,000 pcs.
Leadtime: 1 Week **
Total Price:
0.38 € *
Price list
Quantity
Price per unit*
1 pcs.
0.3832 €
50 pcs.
0.3284 €
100 pcs.
0.2844 €
250 pcs.
0.2535 €
500 pcs.
0.2213 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

Characteristics

  • Capacitance range: 0.2 pF ‒ 350 F
  • Capacity tolerance: ±20 %
  • Dimensions (DxL) in mm: 5.0 x 11.0 to 18.0 x 41.0
  • Lifespan: 4000 ‒ 10000 hours @ +105 °C
  • Mounting style: THT Radial
  • Operating temperature: -40°C to +105°C
  • Recommended soldering: Wave soldering
  • Voltage range (UR): 10 - 100 V(DC)
  • Product series with low leakage current and long lifespan
  • Capacity range: 22 µF ‒ 4700 µF
  • Mounting type: THT Radial
  • Recommended soldering method: Wave soldering

Application:

  • Durable battery applications
  • Filtering
  • Smoothing
  • Energy storage
  • Coupling
  • e.g. Switched-mode power supply, AC/DC converter, adapter, charger, digital camera
  • Durable battery applications
  • Filtering
  • Smoothing
  • Energy storage
  • Coupling
  • e.g. Switched-mode power supply, AC/DC converter, adapter, charger, digital camera
Technical specifications
Connection solder connection
Version polar
Design radial
diameter 8 mm
Capacity 47 µF
Length 11.5 mm
max. operating temperature 105 °C
min. operating temperature -40 °C
Rated voltage (DC) 63 V
Grid 3.5 mm
Ripple current 360 mA
Tolerance ±20 %
Show similar products 0
Logistics
Country of origin CN
Customs tariff number 85322200
MSL MSL 1
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
1 item in 16 variations
*incl. VAT plus shipping costs
Item description
Total
Price list
diameter
Length
Grid
Capacity
Ripple current
Design
Version
Tolerance
Connection
min. operating temperature
Rated voltage (DC)
max. operating temperature
Electrolytic capacitor, 820 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 16 mm
Electrolytic capacitor, 820 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 16 mm
Order No.:
 14D1456
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040780016
Available: 50 pcs. Available in 5 Days: 997 pcs. Leadtime: 1 Week **
Total Price: 3.92 € *
1 pcs.
3.9151 €
50 pcs.
3.3439 €
100 pcs.
2.9036 €
250 pcs.
2.5823 €
500 pcs.
2.2610 €
16 mm
31.5 mm
7.5 mm
820 µF
2.4 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 100 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 10 mm
Electrolytic capacitor, 100 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 10 mm
Order No.:
 14D1450
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040775006
Available: 11 pcs. Available in 5 Days: 8,504 pcs. Leadtime: 1 Week ** Next delivery: 50 pcs. on 2024-06-17
Total Price: 0.64 € *
1 pcs.
0.6426 €
50 pcs.
0.5438 €
100 pcs.
0.4736 €
250 pcs.
0.4225 €
500 pcs.
0.3689 €
10 mm
12.5 mm
5 mm
100 µF
640 mA
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 470 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm
Electrolytic capacitor, 470 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm
Order No.:
 14D1454
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040778013
Available: 50 pcs. Available in 5 Days: 6,720 pcs. Leadtime: 1 Week **
Total Price: 2.36 € *
1 pcs.
2.3562 €
50 pcs.
2.0111 €
100 pcs.
1.7493 €
250 pcs.
1.5589 €
500 pcs.
1.3566 €
13 mm
30 mm
5 mm
470 µF
1.8 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 1000 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 18 mm
Electrolytic capacitor, 1000 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 18 mm
Order No.:
 14D1459
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040781018
Available: 50 pcs. Available in 5 Days: 9,625 pcs. Leadtime: 1 Week **
Total Price: 4.62 € *
1 pcs.
4.6172 €
50 pcs.
3.9389 €
100 pcs.
3.4272 €
250 pcs.
3.0464 €
500 pcs.
2.6656 €
18 mm
31.5 mm
7.5 mm
1000 µF
2.8 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 47 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm
Electrolytic capacitor, 47 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm
Order No.:
 14D1446
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040774002
Available: 36 pcs. Available in 5 Days: 10,000 pcs. Leadtime: 1 Week **
Total Price: 0.38 € *
1 pcs.
0.3832 €
50 pcs.
0.3284 €
100 pcs.
0.2844 €
250 pcs.
0.2535 €
500 pcs.
0.2213 €
8 mm
11.5 mm
3.5 mm
47 µF
360 mA
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 56 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm
Electrolytic capacitor, 56 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm
Order No.:
 14D1447
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040774003
Available: 50 pcs. Leadtime: 22 Weeks **
Total Price: 0.46 € *
1 pcs.
0.4570 €
50 pcs.
0.3891 €
100 pcs.
0.3380 €
250 pcs.
0.2999 €
500 pcs.
0.2630 €
8 mm
11.5 mm
3.5 mm
56 µF
380 mA
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 270 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm
Electrolytic capacitor, 270 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm
Order No.:
 14D1452
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040778011
Available: 50 pcs. Available in 5 Days: 1,187 pcs. Leadtime: 1 Week **
Total Price: 1.51 € *
1 pcs.
1.5113 €
50 pcs.
1.2852 €
100 pcs.
1.1186 €
250 pcs.
0.9996 €
500 pcs.
0.8687 €
13 mm
20 mm
5 mm
270 µF
1.2 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 1200 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 18 mm
Electrolytic capacitor, 1200 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 18 mm
Order No.:
 14D1460
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040781020
Available: 50 pcs. Available in 5 Days: 457 pcs. Leadtime: 1 Week **
Total Price: 6.26 € *
1 pcs.
6.2594 €
50 pcs.
5.3312 €
100 pcs.
4.6529 €
250 pcs.
4.1293 €
500 pcs.
3.6176 €
18 mm
35.5 mm
7.5 mm
1200 µF
3 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 1000 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 16 mm
Electrolytic capacitor, 1000 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 16 mm
Order No.:
 14D1457
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040780017
Available: 45 pcs. Available in 5 Days: 9,271 pcs. Leadtime: 1 Week **
Total Price: 4.90 € *
1 pcs.
4.9028 €
50 pcs.
4.1769 €
100 pcs.
3.6414 €
250 pcs.
3.2368 €
500 pcs.
2.8322 €
16 mm
35.5 mm
7.5 mm
1000 µF
2.5 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 1200 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 16 mm
Electrolytic capacitor, 1200 µF, 63 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 16 mm
Order No.:
 14D1458
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040780019
Available: 36 pcs. Available in 5 Days: 7,684 pcs. Leadtime: 1 Week **
Total Price: 5.49 € *
1 pcs.
5.4859 €
50 pcs.
4.6767 €
100 pcs.
4.0698 €
250 pcs.
3.6176 €
500 pcs.
3.1654 €
16 mm
41 mm
7.5 mm
1200 µF
2.92 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 33 µF, 63 V (DC), ±20 %, radial, pitch 2.5 mm, Ø 6.3 mm
Electrolytic capacitor, 33 µF, 63 V (DC), ±20 %, radial, pitch 2.5 mm, Ø 6.3 mm
Order No.:
 14D1445
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040773001
Available: 40 pcs. Available in 5 Days: 7,554 pcs. Leadtime: 1 Week **
Total Price: 0.23 € *
1 pcs.
0.2297 €
50 pcs.
0.1964 €
100 pcs.
0.1714 €
250 pcs.
0.1523 €
500 pcs.
0.1333 €
6.3 mm
11 mm
2.5 mm
33 µF
260 mA
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 120 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm
Electrolytic capacitor, 120 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm
Order No.:
 14D1449
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040774007
Available: 48 pcs. Available in 5 Days: 596 pcs. Leadtime: 1 Week **
Total Price: 0.70 € *
1 pcs.
0.7021 €
50 pcs.
0.5950 €
100 pcs.
0.5212 €
250 pcs.
0.4617 €
500 pcs.
0.4046 €
8 mm
20 mm
3.5 mm
120 µF
700 mA
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 680 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm
Electrolytic capacitor, 680 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm
Order No.:
 14D1455
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040778015
Available: 36 pcs. Leadtime: 22 Weeks **
Total Price: 3.11 € *
1 pcs.
3.1059 €
50 pcs.
2.6537 €
100 pcs.
2.3086 €
250 pcs.
2.0587 €
500 pcs.
1.7969 €
13 mm
40 mm
5 mm
680 µF
2.2 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 220 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 10 mm
Electrolytic capacitor, 220 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 10 mm
Order No.:
 14D1451
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040775010
Available: 40 pcs. Available in 5 Days: 8,652 pcs. Leadtime: 1 Week **
Total Price: 1.05 € *
1 pcs.
1.0472 €
50 pcs.
0.8925 €
100 pcs.
0.7735 €
250 pcs.
0.6902 €
500 pcs.
0.6069 €
10 mm
25 mm
5 mm
220 µF
1.1 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 82 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm
Electrolytic capacitor, 82 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm
Order No.:
 14D1448
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040774004
Available: 50 pcs. Available in 5 Days: 3,945 pcs. Leadtime: 1 Week **
Total Price: 0.53 € *
1 pcs.
0.5284 €
50 pcs.
0.4498 €
100 pcs.
0.3927 €
250 pcs.
0.3475 €
500 pcs.
0.3046 €
8 mm
16 mm
3.5 mm
82 µF
460 mA
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
Electrolytic capacitor, 330 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm
Electrolytic capacitor, 330 µF, 63 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm
Order No.:
 14D1453
Manufacturer:
 Würth Elektronik eiSos
Manufacturer SKU:
 860040778012
Available: 50 pcs. Available in 5 Days: 10,000 pcs. Leadtime: 1 Week **
Total Price: 1.63 € *
1 pcs.
1.6303 €
50 pcs.
1.3923 €
100 pcs.
1.2138 €
250 pcs.
1.0710 €
500 pcs.
0.9401 €
13 mm
25 mm
5 mm
330 µF
1.6 A
radial
polar
±20 %
solder connection
-40 °C
63 V
105 °C
*incl. VAT plus shipping costs
**Subject to prior sale
Images may differ
