SMDTF03330TB00MQ00 | Wima
Film capacitor, 330 nF, ±20 %, 250 V (DC), PET, SMDTF03330TB00MQ00
Order No.: 41D4493
EAN: 4099879816467
MPN:
SMDTF03330TB00MQ00
SMD2824PET 0,33UF/250V
Series: SMD-PET
Unit Price (€ / pc.)
1.1662 € *
Available: 11 pcs.
Total Price:
11.66 € *
Price list
Quantity
Price per unit*
10 pcs.
1.1662 €
50 pcs.
1.0234 €
250 pcs.
0.8925 €
1000 pcs.
0.7735 €
2500 pcs.
0.7140 €
*incl. VAT plus shipping costs
Subject to prior sale
Film capacitor, SMDTF03330TB00MQ00, WIMA
The SMDTF03330TB00MQ00 is a SMD capacitor. This product is a safe protection of the capacitor element against mechanical and thermal stresses during processing and operation.
Features
- Self-healing
- Suitable for lead-free soldering
- Vacuum-deposited
- Tinned wire
- Solvent-resistant, flame-retardent plastic case, UL 94 V-0
Applications
- By-pass
- Blocking
- Coupling and decoupling
- Timing
Technical specifications
| Rated voltage (DC) | 250 V | |
| Dielectric material | PET | |
| Capacity | 330 nF | |
| Width | 6.1 mm | |
| Height | 5 mm | |
| Length | 7.2 mm | |
| Rated voltage (AC) | 160 V | |
| Design | SMD 2824 | |
| min. operating temperature | -55 °C | |
| Tolerance | ±20 % | |
| max. operating temperature | 125 °C | |
| Number of pins | 2 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85322500 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
