MKX2AW31004B00KSSD | Wima

MKP film capacitor, 100 nF, ±10 %, 630 V (DC), PP, 15 mm, MKX2AW31004B00KSSD

Order No.: 50D1402
EAN: 4099891563943
MPN:
MKX2AW31004B00KSSD
MKP-X2 0.1 µF 305 VAC
Wima
MKX2AW31004B00KSSD Wima Film Capacitors
Image may differ
Print
Key Specification:
Capacity 100 nF
Rated voltage (DC) 630 V
Tolerance ±10 %
Dielectric material PP
Download Datasheet Technical specifications

No longer in assortment

Unit Price (€ / pc.)
0.4046 € *
Available in 4 Days: 1,610 pcs. - if ordered today
Total Price:
202.30 € *
*incl. VAT plus shipping costs
Subject to prior sale
500 pcs.
0.4046 €
Description
Technical specifications
Download
Logistics
Compliance

MKP film capacitor, MKX2AW31004B00KSSD, Wima

MKP film capacitor, 100 nF, ±10 %, 630 V (DC), PP, 15 mm

Features

  • Safe regeneration
  • High interference suppression level due to low-attenuation design with low ESR
  • Compliant RoHS 2011/65/EU
Technical specifications
Rated voltage (DC) 630 V
Dielectric material PP
Capacity 100 nF
Grid 15 mm
Width 5 mm
Height 11 mm
Length 18 mm
Design radial
min. operating temperature -55 °C
Tolerance ±10 %
max. operating temperature 105 °C
Number of pins 2
Articles of same specification 0
Logistics
Country of origin DE
Customs tariff number 85322500
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
