MKS4J032204F00KSSD | Wima
MKS film capacitor, 220 nF, ±10 %, 630 V (DC), PET, 15 mm, MKS4J032204F00KSSD
Unit Price (€ / pc.)
0.8092 € *
Standard delivery time from the manufacturer is: 23 Weeks
Film capacitor, MKS4J032204F00KSSD, WIMA
The MKS4J032204F00KSSD is a metallized capacitor with thin layers of aluminium. The layers are vacuum-deposited on the insulating film as conducting electrodes. In the case of a breakdown, the short circuit current causes the thin metal coating to evaporate around the point of failure and an insulating area is formed. This product is used in the high frequency field. This includes resonant circuits, power supplies, deflection circuits, oscillator circuits and audio equipment.
Features
- High volume/capacitance ratio
- Self-healing
- Vacuum-deposited
- Tinned wire
- Solvent-resistant, flame-retardent plastic case with epoxy resin seal UL 94 V-0
Applications
- By-pass
- Blocking
- Coupling and decoupling
- Timing
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (AC) | 400 V | |
| Capacity | 220 nF | |
| Design | radial | |
| Rated voltage (DC) | 630 V | |
| Width | 8 mm | |
| Number of pins | 2 | |
| max. operating temperature | 125 °C | |
| Height | 15 mm | |
| Tolerance | ±10 % | |
| Grid | 15 mm | |
| Dielectric material | PET | |
| min. operating temperature | -55 °C | |
| Length | 18 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Original Packaging | Bulk with 1,200 pieces |
| Customs tariff number | 85322500 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
