MKS0C032200C00KC00 | Wima
MKS film capacitor, 220 nF, ±10 %, 63 V (DC), PET, 2.5 mm, MKS0C032200C00KC00
Unit Price (€ / pc.)
1.0115 € *
Available: 1,067 pcs.
Total Price:
1.01 € *
Price list
Quantity
Price per unit*
1 pcs.
1.0115 €
10 pcs.
0.6307 €
50 pcs.
0.5355 €
250 pcs.
0.4760 €
1000 pcs.
0.4165 €
*incl. VAT plus shipping costs
Subject to prior sale
Film capacitor, MKS0C032200C00KC00, WIMA
The MKS0C032200C00KC00 is a miniature capacitor. This product is contacted at the end surfaces and have very low self-inductance due to the small pin spacing of the capacitor and its fully contacted electrodes, the pulse and current loading capacities basically increase, the smaller the Pitch can be designed, because - provided that the thickness of the film is the same - a longer band length is needed to achieve a particular capacitance value.
Features
- High volume/capacitance ratio and reduced base
- Pitch 2.5 mm
- Self-healing
- Vacuum-deposited
- Solvent-resistant, flame-retardent plastic case with epoxy resin seal UL 94 V-0
Applications
- By-pass
- Blocking
- Coupling and decoupling
- Timing
Technical specifications
| max. operating temperature | 105 °C | |
| Grid | 2.5 mm | |
| Tolerance | ±10 % | |
| Height | 7.5 mm | |
| min. operating temperature | -55 °C | |
| Number of pins | 2 | |
| Capacity | 220 nF | |
| Length | 4.6 mm | |
| Design | radial | |
| Rated voltage (AC) | 40 V | |
| Width | 3 mm | |
| Rated voltage (DC) | 63 V | |
| Dielectric material | PET |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85322500 |
Compliance
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
