The WD50 10R 1% (F) is a high quality, high stability aluminium housed power resistor designed for direct heat sink attachment. It has a good electrical stability, reliability and is mechanically very rigid.
Features
ohmic resistance | 10 Ω | |
Version | high load wire resistor | |
Design | chassis | |
Width | 30 mm | |
Height | 17 mm | |
Length | 50.1 mm | |
Power | 50 W | |
max. operating temperature | 250 °C | |
min. operating temperature | -25 °C | |
Assembly | chassis mounting | |
nominal load capacity without cooling surface | 25 W | |
Tolerance | ±1 % | |
Temperature coefficient | 60 ppm/K |
Country of origin | IN |
Customs tariff number | 85332100 |
RoHS conform | Yes |
Date of RoHS guidelines | 3/31/15 |
SVHC free | Yes |
