LRMAP3920B-R0005FT | Welwyn
Resistor, metal alloy, SMD 3920, 500 µΩ, 5 W, ±1 %, LRMAP3920B-R0005FT
Unit Price (€ / pc.)
1.0115 € *
Available: 1,940 pcs.
Total Price:
10.12 € *
Price list
Quantity
Price per unit*
10 pcs.
1.0115 €
50 pcs.
0.8925 €
250 pcs.
0.7735 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD precision resistors, size 3920, tolerance 1.0 %, type TT Electronics LRMA.
Suitable for use as low-resistance and low-inductance resistor; Inductance: max. 3.0 nH. Tolerance: 1.0 %. Material: metal alloy. Certification: AEC-Q200. Dimensions: L 10, W 5.2, H 0.67 to 1.5 mm. Operating temperatures: –55 to +170 °C. Stability (on rated load) deviation: 0.5 % after 1000 h. Sliding scale prices are valid exclusively for the quantity per resistance value ordered.
Technical attributes (type, resistance value, power, temperature coefficient (TC)): 0R0005, 5.0 W, TC ±70 ppm/°C
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Temperature coefficient | ±70 ppm/K | |
| Technology | metal alloy | |
| Tolerance | ±1 % | |
| Design | SMD 3920 | |
| ohmic resistance | 500 µΩ | |
| Power | 5 W | |
| Height | 0.85 mm | |
| max. operating temperature | 170 °C | |
| min. operating temperature | -55 °C | |
| Length | 10 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85331000 |
| Country of origin | MX |
| Original Packaging | Reel with 3,000 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
